2″ Band Clamp Pump

2″ Band Clamp Pump

2″ BAND CLAMP PUMP

2″ Band Clamp Pump
  • Ratio 1:1
  • Maximum flow rate: 185 GPM (700 LPM)
  • Displacement per cycle: 1.4 gallons (5.3 liters)
  • Air inlet (female): 3/4 - 14 NPTF-1
  • Fluid inlet/outlet: 2-11-1/2 NPTF -1 Rp 2 (2-11 BSP parallel)
  • Maximum operating pressure: 120 psi (8.3 bar)
  • Suspended solids maximum diameter: 1/4” (6.4 mm)
  • Weight: 75 lbs. (34.02 kg)
  • Maximum dry suction lift: 18 feet (5.4 meters)
  • Maximum wet suction lift: 31 feet (9.4 meters)
  • Sound level: 70 PSI (4.8 bar) 60 cycles/minute 85.0 db(A)
  • Muffler included: 67389

2“ ALUMINUM BAND CLAMP PUMP MODELS
BD Series Flyer

BD20X-XXX-XXX-AXX OPERATOR’S MANUAL
2″ Band Clamp Diaphragm Pump

BD20X-XXX-XXX-AXX SALES & ENGINEERING DATA
2” BAND CLAMP DIAPHRAGM PUMP

DIAPHRAGM AND PISTON PUMPS FOR THE MARINE INDUSTRY
DIAPHRAGM AND PISTON PUMPS FOR THE MARINE INDUSTRY

BD20X-XXX-XXX-AAF CAD STEP FILE
2″ Aluminum Band Clamp Pump

BD20 X     - X A S     - X X X     - A X X
Model Series
BD20 - Standard Pump
Center Section
A Aluminum
Connections
A NPTF Thread
B BSP Thread
Wetted Parts
A Aluminum
Hardware
S Stainless Steel
Seat Material
A Santoprene®
C Hytrel®
F Aluminum
S 316L Stainless Steel
Ball Material
A Santoprene®
C Hytrel®
S Stainless Steel
T PTFE
Diaphragm Material
A Santoprene®
C Hytrel®
K PTFE Composite
T PTFE/ Santoprene®
Revision Level
Specialty Code
Fluid control options for pump with electronic interface (BE20 model). See complete description on next page
Specialty Code
Fluid control options for pump with electronic interface (BE20 model). See complete description on next page
